Rotary Mud Circulation Crawler Well Drilling Rig 400m Depth 20T Lifting Force JKS400B

The JKS400B rotary mud circulation crawler well drilling rig is a workhorse for unconsolidated and mixed ground conditions where mud rotary drilling delivers the fastest penetration. A powerful 92kW engine drives a high-pressure variable pump that powers rotation, feed and winch functions with precise control. The rig uses cutting bits and cone bits with mud circulation to clean the borehole, making it exceptionally effective in sand, clay, gravel and weathered rock layers. With a 20T lifting force and 9000N.m rotation torque, the machine handles 400m deep holes in diameters from 105mm to 350mm while keeping the drill string under full control at all times.

• Mud rotary efficiency: high-flow mud circulation cleans cuttings continuously, allowing fast penetration in soft and mixed formations.
• 20T pullback power: confident handling of long drill strings, stuck tools and casing work in deep holes.
• Stable centralizer: 0.7m centralizer height keeps the borehole straight, protecting casing and pump installation later.
• Stepless speed control: 0-40/80rpm hydraulic variable rotation matches bit speed to formation hardness.
• Integrated winch: 1.5T small winch assists pipe handling and reduces manual labor on the drill floor.
• Crawler mobility: self-propelled tracks move the rig between boreholes and around site without a trailer.

The JKS400B is ideal for agricultural irrigation wells, community water supply boreholes, dewatering wells, foundation drainage and shallow geothermal installations in plains and river basins. Mud rotary mode keeps the hole stable in sandy and collapsing strata, while the option of DTH operation extends the rig into moderately hard rock when geological conditions change mid-hole.

Machines are prepared with rust-preventive coating, steel-frame seaworthy crating and full hydraulic system testing before dispatch. A complete tool kit, spare seals, operation and maintenance documentation, and one-year warranty on major components are provided. Our engineers offer remote setup guidance and on-site training arrangements for first-time buyers.
