High Pressure JKS500F Reverse Circulation Drill Rig 4.5MPa Working Pressure 26T Lifting Force 132kW Power

This high pressure JKS500F reverse circulation drill rig is configured for formations that demand maximum air energy: deep hard rock, karstic limestone, and geothermal environments. The rig supports working air pressures up to 4.5 MPa with air consumption from 16 to 60 m3/min, allowing it to drive high-pressure DTH hammers and RC hammers at their rated performance. Backing the air system is a 132 kW diesel engine, and the 9000 Nm rotation torque keeps large bits turning through the toughest ground. The 26 ton maximum lifting force provides the capacity to recover long drill strings and stuck equipment safely, which is critical in deep, difficult holes.

• 4.5MPa Working Pressure: full performance for modern high-pressure DTH and RC hammer systems.
• 16-60 m3/min Air Delivery: flexible air volume matching for different hole sizes and depths.
• 9000Nm Rotation Torque: sustained rotary power for large-diameter bits in hard rock.
• 26T Lifting Force: safe handling of long strings and fishing operations.
• 132kW Engine: dependable power with good fuel economy for high-pressure drilling.
• Optional Auxiliary Systems: hydraulic generator, mud pumps, and foam pump options expand capability.

This high pressure variant of the JKS500F is used for deep geothermal drilling, hard rock water wells, mineral exploration with RC hammers, and large-diameter boreholes in karst terrain. Geothermal projects benefit from the rig's ability to maintain high pressure at depth, and RC exploration programs rely on the clean sample return and fast penetration the machine delivers. The optional centrifugal mud pump (1500 L/min), plunger mud pump (500 L/min), and foam pump (20 L/min) let contractors adapt the same rig to mud rotary drilling when formations require it, making this one of the most versatile deep-drilling platforms in its weight class.

The high pressure configuration is factory tested at full working pressure with the air system performance recorded in the delivery documents. Shipping is arranged by 40ft open top container or flat rack with the mast, hoses, and auxiliary pumps protected. The documentation pack includes CE certification, engine papers, hydraulic and pneumatic schematics, and a maintenance manual. Our support engineers provide commissioning guidance and can help select the correct hammer, bit, and rod package for your target formation.
